High Quality hybrid solar inverter 5Kw inverter wall mounted
Efficiency:Advanced MPPT with up to 99.9% efficiency.Multiple charge and discharge modes are available.
Reliable:Outputs high-quality pure sine wave AC power.Reliable output for long periods at rated power.
Safety:360 degrees of security from hardware to software.With IEC, SAA, cETL ,FCC certification.
Specification：
| Model Number | HSI 3000U |
| Rated Output Power | 3,000W |
| Peak Power | 6000VA |
| Rated Output Voltage | 120Vac, single-phase |
| Load Capacity of Motors | 2HP |
| Rated AC Frequency | 50Hz/60Hz |
| Battery Type | Lead-acid / Li-ion / User-defined |
| Rated Battery Voltage | 24V |
| Voltage Range | 20～33Vdc |
| Max. PV Charging Current | 60A |
| Max. Utility/Generator Charging Current | 40A |
| Max. Hybrid Charging Current | 100A |
| Max. PV Array Power | 1600W |
| Max. Input Current | 40A |
| Dimensions | 378*280*103mm (1.24*0.92*0.34ft) |
| Weight | 6.8kg |
| Protection Degree | IP20, indoor onIy |
| Operating Temp. Range | ,-10℃~55℃ |
| Embedded Interfaces | RS485 / USB / Dry contact |
| External Module (optional) | Wi-Fi / GPRS |
